| General |
| Maximum Number of Cameras |
Unlimited (Please Refer to System Requirements Below) |
| Support OS |
Windows 8, 7, Vista, XPWindows Server 2012, 2008, 2003, 2000 |
| LiveView (Local Display) |
| Max. Channel |
64-Channel (With dual monitor) |
| Layout |
Multi Layout display: 1x1, 2x2, 1+5, 1+7, 3x3, 1+12, 4x4, 5x5, 6*6, 8*8, Single Layout display, Full screen display, Sequential display |
| Stream Application |
Stream Selection |
| Playback |
| Max. Channel |
9 Channel |
| Layout |
Multi Layout display: 1x1, 2x2, 3x3, Single Layout display, Full screen display |
| Playback Mode |
Server & On-board Storage |
| Playback Control |
Play, Rewind, Pause, Stop, Next / Previous Video Start, Speed Control |
| Search Mode |
Date & Time, Timeline Event, Alarm, Timeline |
| Video |
| Video Format |
H.264 AVC, H.265 |
| Video Resolution |
Up to 5 Megapixel |
| Video Enhancement |
Brightness, Hue, Contrast, Saturation |
| Audio |
| Audio Format |
G.711 |
| Audio Capability |
Two Way |
| Audio Control |
Mute & Sound Play |
| Record |
| Recording Time (sec.) |
Post-Record: 10-60 |
| Recording Stream |
Single |
| Recording Mode |
Continuous (Schedule, Manual, Event) * |
| Recording Setting |
Recycle |
| Recording File Format |
H.264 or H.265 |
| Alarm Management |
| Alarm Setting |
LiveView Alarm Notification, Alarm Count |
| eMap |
| Source |
Import Picture * |
| Marked |
Add, Remove, Indicator LiveView * |
| PTZ |
| PTZ Control |
Panel Control |
| PTZ Operation |
Direction Control, Zoom, Focus, Iris, Preset, Tour, Speed |
| Export |
| Snapshot |
BMP |
| Export file |
AVI |
| System |
| User Management |
Authentication: Basic Account |
| Date & Time |
Sync PC |
| Language |
Czech, English, French, German, Italian, Japanese, Persian,Portuguese, Russian, Spanish, Simplified Chinese |
| Camera Integration |
| Camera Insert |
Manual, Search, Auto discovery |
| Basic Setting |
Date & Time, video standard, DST |
| Connection Setting |
TCP/IP, DAS, Cloud, Email, FTP, DDNS, PPPoE, RTSP |
| Video Setting |
Video Stream, Compression, Resolution, FPS, Video Quality |
| Audio Setting |
On/Off |
| Event |
Motion detection, Abnormal |
| Local Storage |
Utilities, recording schedule |
