6 HDMI Monitors Video Wall Controller

6 HDMI Monitors Video Wall Controller

Model:5809-74
Channel: 16CH analog
Harddrive: 1 Units x 6TB
Standard: H.264
Local display: HDMI/VGA
 0 (0)
Overview
Specification
Rated Voltage and Power
Rated Voltage and Power 110–240 VAC; 50/60 Hz; 1.5A
External power adapterDC output DC12V 4A
Video
Video Standard PAL or NTSC
Compression H.264
Outputs VGA/HDMI
Inputs 16 composite video 1 Vpp 75 ohm automatic termination
Audio
Inputs 1 line in , mono RCA,1 Vpp, 10 kohm
Output 1 line out, mono RCA, 1 Vpp, 10 kohm
Compression G.711
Sampling rate 8 kHz per channel
Monitors
VGA/HDMI Live, playback, menus
Live Resolution SVGA: 800x600, 1024x768, 1280x1024, 1360x768, 1440x900, 1920x1080PAL: 704x576, NTSC: 704x480
Display Modes
Screen Full, full sequence, quad, multi-screen (live and playback), event call-up (live)
Frame rate PAL/NTSC 25/30 IPS per channel (real time)
Multi-screen mode 4 channels 1, 2x2, 3x3, 4x4
Digital Zoom Yes
Display languages Arabic, Portuguese, English, French, Deutscher, Russian, HUNGARIAN, ITALIAN, Japanese, POLAND, Roman, Chinese, Spanish, Turkish, SUOMI
Alarm Handling
Inputs 4 input
Outputs 1 output
Events Alarm input, Motion detect, Video Blind, Video Loss,
Remote notification Via Control Center software, email, Push message
Malfunction relay Disk space low, IP conflict, Disk failures
Connections
Ethernet 10/100Base-T, auto-sensing, half/full duplex, RJ45
USB Two USB 2.0 ports
Network
Protocols HTTP, TCP/IP, ARP, RTSP, RTP, UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP
Cameras 16*4M@8fps(AHD);16*3M@10fps(AHD);16*1080P @15fps (5 in 1)
Storage
Internal HDD 2 unit
Redundancy N/A
Exporting
USB Flash memory
Network Golbong Software
Security
Password protection Multi-level
Recording
Overwrite modes Continuous, overwrite
Playback
Decoding Capacity 8-CH
Playback function Fast forward/reverse, frame forward /reverse,freeze
Digital Zoom yes
Search mode Date/time, Event (motion, input)
Mechanical
Dimensions (W x D x H)(excluding cabling) 255(L) x 44(H) x 236(W)
Weight TBA
Environmental
Operating temperature +5 °C to +45 °C (+41 °F to +113 °F)
Storage temperature -25 °C to +70 °C (-13 °F to +158 °F)
Relative humidity Operating: <93 % non-condensing Storage: <95 % non-condensing
Ordering Information
Analog HD Video Recorder 3554-28
Documents
Reviews
Share your thoughts with others
Write A Review
0 Reviews & Ratings
(0)
(0)
(0)
(0)
(0)
SORT BY:
SORT BY:
Question & Answer
QUESTION & ANSWER
Tell us your questions. We’ll reply ASAP.
ASK A QUESTION
SORT BY:
SORT BY:

6 HDMI Monitors Video Wall Controller

Model:5809-74
Channel: 16CH analog
Harddrive: 1 Units x 6TB
Standard: H.264
Local display: HDMI/VGA
  • Overview
  • Specifications
  • Document
  • Reviews
  • Question & Answer

Build the TV wall

The controller can get video from the Video server, IP cameras, DVRs, NVRs and output to the TV walls.

Decode the video without PC platfrom

The operator can program the layout with PC software and save sequences to the decoders.

Program emergency plans with operation software

The operator can create emergency plans with PC software, switch to the plan when the emergency come up on the field.

32-channel maximum output in each monitor

The decoder can decode 8-channel 1080p, 16-channel 720p, 32-channel D1 IP video to each monitor.

Complete open

The decoder can work with 3rd-party ip camera basing on onvif protocols.
